Features
DLC QPL v5.1 Listed
The DesignLights Consortium® (DLC) is a non-profit organization promotes high-quality, energy-efficient lighting products in collaboration with utilities and energy efficiency program members, manufacturers, lighting designers. DLC Listed high performing LED lighting products may qualify for rebates.
CCT and Lumen Selectable
Choose lumen output and color temperature before installation with integrated switch
IP66 Rated
Ingress Protection rating of IP66 for dust and water. Able to protect against powerful water jets.
Emergency Backup Available
When there is a power outage, the emergency backup driver and battery will power the
light for at least 90 mins.
NETWORKED LIGHTING CONTROL
OPTIONS AVAILABLE
Networked Lighting Controls (NLC) offer Luminaire Level Lighting Control (LLLC) based on Bluetooth-enabled Mesh Networking of Luminaires. Individual addressability enables luminaires to be communicated with each other within the zone/network. Luminaires can be grouped, trim and controlled by using the smart device app or connected wall switches. Scheduling, scene and sensors can be added for automation among the lights within the zone/group.
Specs & Variations
MODEL | ||||||||||
FVTB-4D | wattage adjustable | 45W | 38W | 34W | ||||||
CCT adjustable | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K | |
Lumen | 5,850 lm | 5,895 lm | 5,940 lm | 5,054 lm | 5,092 lm | 5,130 lm | 4,624 lm | 4,658 lm | 4,692 lm | |
FVTB-8D | wattage adjustable | 90W | 75W | 65W | ||||||
CCT adjustable | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K | 3500K | 4000K | 5000K | |
Lumen | 11,700 lm | 11,790 lm | 11,880 lm | 9,975 lm | 10,050 lm | 10,125 lm | 8,840 lm | 8,905 lm | 8,970 lm |
* all models are 3500k/4000k/5000k CCT field-adjustable.
Documents & Downloads
FVTB series Product Specification Sheet |
* specifications are subject to change without notice.
FVTB series Installation Guide
* installation instructions are subject to change without notice.
Download IES Files:
FVTB-4D (field-adjustable to 34w/38w/45w, 3500K/4000K/5000K CCT)
FVTB-4D 34W 3500K | FVTB-4D 34W 4000K | FVTB-4D 34W 5000K
FVTB-4D 38W 3500K | FVTB-4D 38W 4000K | FVTB-4D 38W 5000K
FVTB-4D 45W 3500K | FVTB-4D 45W 4000K | FVTB-4D 45W 5000K
FVTB-8D (field-adjustable to 65w/75w/90w, 3500K/4000K/5000K CCT)
FVTB-8D 65W 3500K | FVTB-8D 65W 4000K | FVTB-8D 65W 5000K
FVTB-8D 75W 3500K | FVTB-8D 75W 4000K | FVTB-8D 75W 5000K
FVTB-8D 90W 3500K | FVTB-8D 90W 4000K | FVTB-8D 90W 5000K
wdt_ID | QPL Model No. | Product ID | Version | Classification | Primary Use |
---|---|---|---|---|---|
211 | FVTB-4D-45/38/34-835/840/850 (A3L+B3) | PI6DDDW8 | 5.1 | Standard | Direct Linear Ambient Luminaires |
212 | FVTB-8D-90/75/65-835/840/850 (A3L+B3) | PL34KKUR | 5.1 | Standard | Direct Linear Ambient Luminaires |
