Features
DLC QPL v5.1 Listed
The DesignLights Consortium® (DLC) is a non-profit organization promotes high-quality, energy-efficient lighting products in collaboration with utilities and energy efficiency program members, manufacturers, lighting designers. DLC Listed high performing LED lighting products may qualify for rebates.
Wattage and Color Selectable
Choose wattage and/or color temperature (3500K/4000/5000K) before, during, or after the installation with integrated dip switch.
Control Options
Easier than ever before, factory installed controls enables a smooth installation process, providing options for Bi-Level Microwave Dimming control or Networked Lighting controls. This streamlined approach ensures maximum energy savings.
NSF Certified
Conforms to the requirements of NSF/ ANSI 2 – Food Equipment. Designed and constructed to minimize the risk of contamination, promoting food safety and hygiene throughout the foodservice process.
NETWORKED LIGHTING CONTROL
OPTIONS AVAILABLE
Networked Lighting Controls (NLC) offer Luminaire Level Lighting Control (LLLC) based on Bluetooth-enabled Mesh Networking of Luminaires. Individual addressability enables luminaires to be communicated with each other within the zone/network. Luminaires can be grouped, trim and controlled by using the smart device app or connected wall switches. Scheduling, scene and sensors can be added for automation among the lights within the zone/group.
Specs & Variations
MODEL | CCT | |||
Selectable Wattage / Color | FVTA/2-135 | FVTA/2-115 | FVTA/2-100 | |
FVTA/2-135/115/100 | 5000K | 22,275 lm | 19,320 lm | 17,100 lm |
4000K | 22,680 lm | 19,665 lm | 17,400 lm | |
3500K | 22,005 lm | 19,090 lm | 16,900 lm | |
Selectable Wattage / Color | FVTA/2-200 | FVTA/2-185 | FVTA/2-155 | |
FVTA/2-200/185/155 | 5000K | 32,400 lm | 30,525 lm | 26,040 lm |
4000K | 33,000 lm | 31,080 lm | 26,505 lm | |
3500K | 32,000 lm | 30,155 lm | 25,730 lm |
Build Your Light
Family | Length | Model | Color Temperature | Options |
FVTA/2 | ||||
4D - 4 ft | 100 - 100w | 35 - 3500K | HV - 480v Input | |
115 - 115w | 40 - 4000K | EM - Emergency backup | ||
135 - 135w | 50 - 5000K | MC - Bi-level Microwave Motion and Daylight Dual Sensor | ||
135/115/100 - 135/115/100w Selectable | 35/40/50 - 3500K/4000K/5000K Selectable | AC - Aircraft cable mount kit | ||
155 - 155w | CN - Chain mount kit | |||
185 - 185w | SU - Surge protector | |||
200 - 200w | WBN - Wireless Bluetooth Networked Control (NLC) | |||
200/185/155 - 200/185/155w Selectable | WBM - Wireless Bluetooth Networked Control w/ Microwave motion and daylight sensor (NLC) |
* Ordering information is for reference only. Some product configurations are not available. Please consult spec sheets for specific product availability and for further details.
Documents & Downloads
FVTA series (Gen.2) Product Specification Sheet |
* specifications are subject to change without notice.
FVTA series (Gen.2) Installation Guide
* installation instructions are subject to change without notice.
wdt_ID | GENERATION | SKU | WATTAGE | CCT | IES File |
---|---|---|---|---|---|
46 | 2nd (Latest) | FVTA/2-4D-100-35 | 100 | 3500K | Download IES |
47 | 2nd (Latest) | FVTA/2-4D-100-40 | 100 | 4000K | Download IES |
48 | 2nd (Latest) | FVTA/2-4D-100-50 | 100 | 5000K | Download IES |
49 | 2nd (Latest) | FVTA/2-4D-115-35 | 115 | 3500K | Download IES |
50 | 2nd (Latest) | FVTA/2-4D-115-40 | 115 | 4000K | Download IES |
51 | 2nd (Latest) | FVTA/2-4D-115-50 | 115 | 5000K | Download IES |
52 | 2nd (Latest) | FVTA/2-4D-135-35 | 135 | 3500K | Download IES |
53 | 2nd (Latest) | FVTA/2-4D-135-40 | 135 | 4000K | Download IES |
54 | 2nd (Latest) | FVTA/2-4D-135-50 | 135 | 5000K | Download IES |
55 | 2nd (Latest) | FVTA/2-4D-155-35 | 155 | 3500K | Download IES |
GENERATION | SKU | WATTAGE | CCT | IES File |
*IES files might not cover all options
wdt_ID | QPL Model No. | Product ID | Version | Classification | Primary Use |
---|---|---|---|---|---|
161 | FVTA/2-4D-135/115/100-35/40/50 CCT-(MC, EM, Blank, Both) | S-1EI7YS | 5.1 | Premium | High-Bay Luminaires for Commercial and Industrial Buildings |
162 | FVTA/2-4D-200/185/155-35/40/50 CCT-(MC, EM, Blank, Both) | S-K2RV05 | 5.1 | Standard | High-Bay Luminaires for Commercial and Industrial Buildings |
